Specifications
323.3 ±2.5 mm [12.7 ±0.1 in]
9.0 ±1.0 mm [0.4 ± 0.04 in]
Illustration 7.111 X8 IP21 Internal Fan 2
Illustration 7.112 X8 IP21 Internal Fan 2, 3D View
MG80C502
Design Guide
1151.5 ±2.5 mm [45.3 ±0.1 in]
240.0 ±1.0 mm [9.4 ±0.04 in]
240.0 ±1.0 mm [9.4 ±0.04 in]
300.0 ±1.0 mm [11.8 ±0.04 in]
9.0 ±1.0 mm [0.4 ±0.04 in]
800.0 ±2.5 mm [31.5 ±0.1 in]
1113.4 ±4.0 mm [43.8 ±0.16 in]
1172.1 ±4.0 mm [46.1 ±0.16 in]
Danfoss A/S © 10/2016 All rights reserved.
421.0 ±2.5 mm [16.6 ±0.1 in]
468.0 ±2.5 mm [18.4 ±0.1 in]
68.7 ±2.5 mm [2.7 ±0.1 in]
113
7
7
