Danfoss VLT AHF 005 Design Manual page 104

Specifications
226.8 ±2.5 mm [8.9 ±0.1 in]
7 7
Illustration 7.89 IP21 X5 External Fan 1
Illustration 7.90 IP21 X5 External Fan 1, 3D View
102
VLT
210.5 ±1 mm [8.3 ±0.04 in]
9.0 ±1 mm [0.4 ±0.04 in]
Danfoss A/S © 10/2016 All rights reserved.
®
Advanced Harmonic Filter AHF 005/AHF 010
931 ±4.0 mm [36.7 ±0.16 in]
210.5 ±1 mm [8.3 ±0.04 in]
240.0 ±1 mm [9.4 ±0.04 in]
9.0 ±1 mm [0.4 ±0.04 in]
685.0 ±2.5 mm [27.0 ±0.1 in]
973.0 ±4.0 mm [38.3 ±0.16 in]
370.0 ±2.5 mm [14.6 ±0.1 in]
418.0 ±2.5 mm [16.5 ±0.1 in]
89.0 ±2.5 mm [3.5 ±0.1 in]
MG80C502
