USE AND MAINTENANCE MANUAL – DLC
5.4 Calibration menu
5.4.1 Calibration mode with
weight
Table 25. Calibration mode
Menu Submenu
5.4.2 Access to the
calibration menu
( )
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
NET
Series
Using the on board display or the remote display, the instruments of DLC
can be calibrated (scaled in engineering units) in different ways:

Calibration with sample weights (weights applied on the scale)

Calibration with load cells simulator (electric calibration)

Automatic calibration (with load cells parameters known)

Correction of the zero value

Correction of full scale value
To perform the above steps you must use the menu indicated below:
Description
Calibration with sample weights
Calibration with load cells simulator
Automatic calibration
Correction of full scale value
Correction of the zero value
The procedure described as
change the full scale of the balance.
Follow the instructions in section 5.3.
Use as interface with indicator
Notes
To be made when it has easily sample
weights applicable to the weighing
system (low capacity scales) to obtain
maximum accuracy.
An alternative to the previous way.
To be made with high capacity tanks
and scales, when
sensitivity values are known. Pending
Accuracy: 0.1%
An alternative to the two previous way.
To use if you do not have either of
sample weights or simulator, but only
the sensitivity of the load cells. Pending
Accuracy: 0.2%
To be made to adjust the calibration
value after a system check.
To be made when there are zero
offsets of the weighing system. No
effect on full scale.
must always be performed when you
NET
series
the load cell
