USE AND MAINTENANCE MANUAL – DLC
3.9 RS-232 connection for printer
Table 17. RS-232 connection to the printer
NET
Pin on DLC
TB5-1
TB5-2 (RX instrument)
TB3-3 (TX instrument)

Figure 25. Printer connection through RS232

Table 18. Serial port parameters to be set on the printer
Parameter
Transmission
Baud rate
Word
Stop bit
Parity
LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
NET
Series
It is possible connect the DLC
Connections are described in Figure 25 and Table 17. The configuration of the
serial port to be set on the printer must be that of Table 18.
It is necessary the expansion board -EB.
Pin on printer
GND
TXD printer
RXD printer
The RS232 serial port of the printer must be configured as follows in order to be
compatible with the DLC
Value
Asynchronous
9600
7 bits
1
Even
NET
to a thermal printer with RS-232 connection.
NET
.
Installation
