USE AND MAINTENANCE MANUAL – DLC
3.7 Fieldbus connection
®
3.7.1
Profibus-DP
Table 10. Table connections to Profibus-DP
Pin connector Profibus-DP on DLC
TB2-3
TB2-8

Figure 18. Instrument connection to Profibus-DP

LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
NET
Series
The standard version of the DLC
communication port Fieldbus Profibus-DP
on the TB2 connector as shown in the following table:
®
Fieldbus
NET
Terminal connector Profibus-DP
A
B
®
Fieldbus
Note how the termination on the connector is active on the last Profibus-DP
NET
series instruments are equipped with
®
. The connection should be carried out
®
Description
Tx/Rx +
Tx/Rx -
Installation
Wire
Green
Red
®
node.
Page 28 of 78
