USE AND MAINTENANCE MANUAL – DLC
5.1 Introduction
5.1.1 User interface

Figure 33. Operator interface of DLC

Figure 34. Operator interface with Logic DLC3-RD

LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
NET
Series
5 Use as interface with indicator
The instruments of DLC
use of the instrument.
They are also compatible with remote displays Logic of DLC3-RD series or, in
hazardous areas, with BEKA
NET
port on board the DLC
In order to ensure the displaying of weight, it is necessary to perform the
operations of setting and calibration in kg. Via Fieldbus the value read by the load
cells is always transmitted expressed in divisions.
The instrument operator interface is that shown in Figure 33.
NET
instrument
NET
Using the DLC coupled to a serial display Logic DLC3-RD, you can use the
user interface of the remote display exactly like the one on board the instrument,
with the keyboard and 6-digit display shown in Figure 34.
NET
series are equipped with keyboard and display for local
®
BA488C display. Connection is via RS-485 serial
, as described in paragraph 3.6.
Use as interface with indicator
Page 43 of 78
