USE AND MAINTENANCE MANUAL – DLC
®
3.7.2 Profinet
Table 11. Table connections to Profinet
Pin connector RJ45 on DLC
TB2-1
TB2-2
TB2-3
TB2-6

Figure 19. Instrument connection to Profinet

LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
NET
Series
The instruments of DLC
and integrated switch. In this case, the TB2 connector integrated into the
instrument will present two RJ45 Ethernet ports, allowing cascade connection of
devices.
The connection should be carried out on the TB2 connector as shown in the
following table:
®
Fieldbus
NET
Pin connector RJ45 bus
1
2
3
6
®
Fieldbus
NET
series can also be ordered with Profinet-DP
Description
Tx+
Tx -
Rx +
Rx -
Installation
®
interface
Wire
White-Orange
Orange
White-Green
Green
Page 29 of 78
