USE AND MAINTENANCE MANUAL – DLC
Table 20. Connection for parallel interface type NPN
NET
Pin on DLC
TB6-1
TB6-2
TB6-10
TB6-3
TB6-11
TB6-4
TB6-12
TB6-5
TB6-13
TB6-8
TB6-15

Figure 28. Connection for parallel interface type NPN

LOGIC S.r.l. - M0145Db.docx
Mod. L0006A01 of 30/05/2016
NET
Series
Description
0 Vdc
Out 1 (+24 Vdc)
Out 2 (+24 Vdc)
Out 3 (+24 Vdc)
Out 4 (+24 Vdc)
Out 5 (+24 Vdc)
Out 6 (+24 Vdc)
Out 7 (+24 Vdc)
Out 8 (+24 Vdc)
0 Vdc
Byte Select input (+24Vdc)
Installation
Page 37 of 78
