Table 50. Config12-1: R1D+R2A+R3A+R4A(FL) (continued)
Agile Description
KIT,CRD,NVME,1.6,HHHL,PM17
25B
KIT,CRD,NVME,3.2,HHHL,PM17
25B
KIT,CRD,NVME,6.4,HHHL,PM17
25B
KIT,CRD,NVME,1.6,HHHL,PM17
35
KIT,CRD,NVME,1.6,HHHL,PM17
35,O
KIT,CRD,NVME,3.2,HHHL,PM17
35
KIT,CRD,NVME,3.2,HHHL,PM17
35,O
KIT,CRD,NVME,6.4,HHHL,PM17
35
KIT,CRD,NVME,6.4,HHHL,PM17
35,O
KIT,CRD,NVME,750GB,HHHL,P
4800X
Removing the expansion card risers
Prerequisites
1. Follow the safety guidelines listed in the
2. Follow the procedure listed in the
3. Disconnect any cables that are connected to the expansion card.
Steps
1. For Riser 1, loosen the captive screws on the riser.
a. Press the blue release tab and holding the edges lift the expansion card riser from the riser connector on the system board.
NOTE:
The numbers on the image do not depict the exact steps. The numbers are for representation of
sequence.
Supplier
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
SAMSUNG
INTEL
Safety instructions
Before working inside your system
Category
PCIE SSD
PCIE SSD
PCIE SSD
PCIE SSD
PCIE SSD
PCIE SSD
PCIE SSD
PCIE SSD
PCIE SSD
PCIE SSD
on page 46.
on page 47.
Installing and removing system components
Card Priority
12200
12300
12400
12500
12600
12700
12800
12900
13000
13100
127
