Configuration 6: R1C + R2A + R3A + R4C - Dell EMC PowerEdge R7525 Installation And Service Manual

Table 43. Configuration 3: R1A + R2A + R3A + R4A (continued)
Card type
QLogic (OCP: 25 Gb)
Mellanox (OCP: 25 Gb)
SolarFlare (OCP: 25 Gb)
Intel (OCP: 25 Gb)
Intel (OCP: 10 Gb)
Broadcom (OCP: 10 Gb)
QLogic (OCP: 10 Gb)
Broadcom (OCP: 1 Gb)
Intel (OCP: 1 Gb)
Table 44. Configuration 6: R1C + R2A + R3A + R4C
Card type
Dell Serial
NVIDIA (GPU - Low Profile)
NVIDIA (GPU - Full Height)
Dell BOSS Adapter (Full Height)
Dell BOSS Adapter (Low Profile)
Dell PERC Adapter
Mellanox (NIC: 100 Gb - Full Height)
Mellanox (NIC: 100 Gb - Low Profile)
Intel (NIC: 25 Gb - Full Height)
Intel (NIC: 25 Gb - Low Profile)
Mellanox (NIC: 25 Gb - Full Height)
Mellanox (NIC: 25 Gb - Low Profile)
SolarFlare (NIC: 25 Gb - Full Height)
SolarFlare (NIC: 25 Gb - Low Profile)
Broadcom (NIC: 25 Gb - Full Height)
Broadcom (NIC: 25 Gb - Low Profile)
QLogic (NIC: 25 Gb - Full Height)
QLogic (NIC: 25 Gb - Low Profile)
Emulex (HBA: FC32 - Full Height)
Emulex (HBA: FC32 - Low Profile)
QLogic (HBA: FC32 - Full Height)
QLogic (HBA: FC32 - Low Profile)
Emulex (HBA: FC16 - Full Height)
106 Installing and removing system components
Slot priority
Internal slot
Internal slot
Internal slot
Internal slot
Internal slot
Internal slot
Internal slot
Internal slot
Internal slot
Slot priority
4, 8
3, 6
1, 2, 5, 7, 8
1, 2, 5, 7, 8
3, 6
3
1, 2, 5, 7, 8
3, 6
1, 2, 5, 7, 8
3, 6
1, 2, 5, 7, 8
3, 6
1, 2, 5, 7, 8
3, 6
1, 2, 5, 7, 8
3, 6
1, 2, 5, 7, 8
3, 6
1, 2, 5, 7, 8
3, 6
1, 2, 5, 7, 8
3, 6
1, 2, 5, 7, 8
Maximum number of cards
1
1
1
1
1
1
1
1
1
Maximum number of cards
1
2
5
1
1
1
4
2
4
2
4
2
4
2
4
2
4
2
4
2
4
2
4
