4.6

Power Supply Connections

The power supply is pre-installed as part of the Main Chassis. The following table displays the
electrical ratings. Figure 54 shows the proper connections to wire the Power Supply
successfully. There is no separate charger for the Secondary Power Connection - batteries.
Table 14
Terminal
Electrical input ratings
Power supply total current
Battery Fuse
120VAC Installation
240VAC Installation
EARTH
GROUND
LUG
240 VAC
To AC Input
brown
blue
green / yellow
AC Conduit

Figure 54 Power supply connections

!
Attention: DO NOT exceed power supply ratings. Wire as shown.
80
Power Supply Electrical Ratings
Description
120 VAC, 60 Hz, 2 A / 240 VAC, 50 Hz, 1A
9.5 A maximum
Replace with WX-058 Battery Cable Assembly
EARTH
GROUND
LUG
black
brown
120 VAC
To AC Input
black
white
green
AC Conduit
green
Connect batteries after the system main A.C. power is turned on to reduce
sparking.
QX-mini/QX-mini-BP MAIN BOARD
green
white with
blue stripe
Battery
WX-058 Cable Assembly
240V
120V
Neutral
+ -
No Polarity
P3 P4 P1 P2
B ATTE RY
AC
red
blue
black
_
black
red
_
Battery
Signal
Yeo Heung
Transformer Transformer
Yellow wire
Brown wire
Red wire
Black wire
White with
Black wire
blue strip wire
Wiring
