Table 15
LED
Remote Mic Trouble
Relay In 1 ACT
Relay In 1 Trouble
Relay In 2 ACT
Relay In 2 Trouble
Aux 24V Output Trouble
Activity on SLC Circuit
Activity on Synch Input 1
Activity on Synch Input 2
Synch Output 1 Active
Synch Output 2 Active
Synch Out Trouble
NAC 1 Output Active
NAC 1 Trouble
NAC 2 Output Active
NAC 2 Trouble
Power ON (AC)
CPU FAIL
Battery Trouble
Ground Fault Active
i
Note:
90
Descriptions of QX-mini main board LEDs (Continued)
Color
Yellow
Green
Yellow
Green
Yellow
Yellow
Green
Green
Green
Green
Green
Yellow
Red
Yellow
Red
Yellow
Green
Yellow
Yellow
Yellow
Trouble Buzzer provides panel specific audible signal of Trouble or Fault.
Indication Action
Trouble Steady
Active Steady
Trouble Steady
Active Steady
Trouble Steady
Trouble Steady
Active Blinking
Active Steady
Active Steady
Status Steady or Blinking
Status Steady or Blinking
Trouble Steady
Status Steady or Blinking
Trouble Steady
Status Steady or Blinking
Trouble Steady
Status Steady
Trouble Blinking
Trouble Steady
Trouble Steady
Indicators & Controls
