9.1.1 Setting the DIP switch
There is 1 bank of DIP switch bits on the QX-mini main board: SW1.
This DIP switch bank has 8 switches, numbered 1 to 8. Flipping a switch up places it in the ON
position. For the purposes of the configuration tables ON = 1 and OFF = 0. For an
illustration of the DIP switch settings see Figure 69.
i
Note:
ON
OFF

Figure 69 DIP switch positions

Table 18
Panel ID Bit 1
1 ON
2 OFF
3 OFF
4 OFF
5 OFF
6 OFF
The Master Panel must have Panel ID# '1' and the Factory Default of Panel ID of
0 will cause a Trouble indication.
1
0
1 2
Panel Address DIP Switch Bits
Bit 2 Bit 3
OFF OFF
ON OFF
OFF ON
OFF OFF
OFF OFF
OFF OFF
1-0-0-0-0-0-0-0 1-0-0-0-0-0-0-0
3 4 5
Bit 4 Bit 5 Bit 6
OFF OFF OFF
OFF OFF OFF
OFF OFF OFF
ON OFF OFF
OFF ON OFF
OFF OFF ON
Configuration
6 7 8
Bit 7 Bit 8
OFF OFF
OFF OFF
OFF OFF
OFF OFF
OFF OFF
OFF OFF
117
