The local microphone panel controls paging and zone control.
•
Up to six Remote Microphones or LOC panels may be added for making
announcements at locations away from the main panel.
•
The QX-mini can support up to 5 Booster Panels for expansion and added broadcast
power.
•
The Master QX-mini Panel communicates with and streams audio to boosters over RS-
485.
via NAC and/or
Dry Contacts
Figure 65 Conventional fire alarm
3rd
Floor
2nd
Floor
Speakers
1st
Floor
QX-mini
Sample Implementations
QX-mini-RM
QX-mini-RM
QX-mini-RM
FACP
QX-mini-RM
111
