15.0
Appendix E: UL Compatible Speakers
with Mircom QAD-30 QX-mini Amplifier
and Temporal 520Hz Square Wave Low
15.1 Mircom Amplifier
Model
QAD-30
15.2 Mircom Temporal 520Hz Square Wave Low Frequency Signal
UL tested Mircom temporal 520Hz square wave has three matching signal inputs available in
the QX-mini Configurator library. Refer to the following table for recommended signal input
selection for UL application according to the speaker manufacturer and amplifier voltage.
Speaker/
Strobe
Manufacturer
System Sensor
Gentex
Wheelock
130
Description
25 or 70 Volt 30 Watt Amplifier
Temporal 520Hz
Square Wave Low
Frequency Signal
Setting
System Sensor 520Hz
25-70V Temporal 3
System Sensor 520Hz
25-70V Temporal 4
Gentex 520Hz 25-70V
Temporal 3
Gentex 520Hz 25-70V
Temporal 4
Wheelock 520Hz 25V
Temporal 3
Wheelock 520Hz 25V
Temporal 4
Wheelock 520Hz 70V
Temporal 3
Wheelock 520Hz 70V
Temporal 4
Frequency Signal
Amplifier Voltage Setting
QAD-30
25V
X
X
X
X
X
X
70V
X
X
X
X
X
X
