1.1

The QX-mini Emergency and Fire Alarm Audio System

The QX-mini operates either as a mass notification audio system or as part of a fire alarm
system. Conventional fire alarm systems control the QX-mini with relays. Any of the Mircom/
Secutron panels listed in Table 2 can control the QX-mini.
Mircom's QX-mini is an emergency and fire alarm audio system designed to provide
notification for small to medium applications. The QX-mini supplies 30W for audio output and
5A for NAC. The optional QAD-30 increases audio output to 60W.
Optional QX-mini-BP Booster Panels provide support for a distributed system. These Booster
Panels have the same output as the QX-mini but do not have microphones or user interface
panels. Up to five Booster Panels can be connected to a QX-mini.
For a list of QX-mini models, components, and accessories, see Table 1.
1.1.1 QX-mini Models and Components

Table 1 QX-mini Models, Components, and Accessories

Model
QX-mini
QX-mini-BP
QX-mini-RM
QX-mini-LOC
QAD-30
QAS-2X8
QAZT-5302DS
i
Note:
10
Description
QX-mini Audio System Master Panel with main display, blank plate,
microphone, backbox, and front door
QX-mini Audio System Booster Panel with deadfront and backbox
Remote Microphone for the QX-mini Audio System
Note: Not for use in Canada
Local Operating Console for QX-mini with main display, blank
plate, microphone, deadfront, backbox, and front door
Note: Not for use in Canada
30W Amplifier Module
QX-mini Audio Zone Splitter
24 zone controller
For more accessories, see section 2.1 QX-mini Components on page 14.
