4.7

UL Power-limited Wiring Requirements

TS10
TS2 TS16
RELAY
AUX RMIC
ALARM
AUDIO AUDIO IN
+ S -
+OUT- +IN- + 1 - + 2 - NO NC C
brown
EARTH
black
GROUND
LUG
green
120 VAC
To AC Input
black
white
green
AC Conduit

Figure 55 UL Power-limited circuits

Wires connected to AC power and Batteries are NOT POWER-LIMITED. AC power branch
circuit has 15A circuit breaker rating.
i
Note:
TS17
TS5 TS4 TS3 TS6
AC COM RS-485 RS-485
RMIC
OUT
TBL TBL RS-485
NO NC C NO NC C + S - + S -
blue with
white stripe
blue
Non Power-limited
Wires connected to NON POWER-LIMITED circuits MUST be at least 1/4 inches
away from wires connected to POWER-LIMITED circuits.
Power-limited
TS1 TS14 TS9
TS11
AUX SYNCH SYNCH SYNCH
SLC
IN 24V
INPUT 1
+ - + + + +
+ S - - - -
+
-
No Polarity
P3 P4 P1 P2
red
WX-058 Cable Assembly
Battery
TS12 TS13 TS7
OUTPUT NAC 1
INPUT 2
+ + - + + - -
- - + 1 - + 2 -
Non Power-limited
black
_
black
red
_
Battery
Wiring
TS8
NAC 2
+ + - -
