8. Remove necessary knockouts and attach conduit. Keep the lower left knockout for the
dedicated AC power in.
Knockouts
Dedicated
AC Power
Knockout
and
Conduit
Figure 5
9. Attach the doors to the chassis and then secure the ground straps to the doors using the
wingnuts removed in step 3.
32
Conduit knockouts
Installation
Knockouts
