Figure 29 Exploded View Of Qx-Mini-Loc Showing Mounting Of Rax-Lcd - Mircom QX-mini Installation And Operation Manual

Emergency and fire alarm audio system
Hide thumbs Also See for QX-mini:
Table of Contents

Advertisement

Same board as
QX-mini-RM
Backbox

Figure 29 Exploded view of QX-mini-LOC showing mounting of RAX-LCD

Included bracket
CH-976 for RAX-LCD and
RAXN-LCD (use 4 screws
attached to blank plate)
Indicators and Controls
(RAX-LCD shown in the
upper window)
Installation
Dead Front
Door
59
