3.2.7 Flush Mounting the QX-mini-LOC
To Flush Mount the Enclosure
1. Open the QX-mini-LOC.
2. Unscrew the four screws that secure the CH-1139A PCB bracket to the backbox.
Knockouts
Figure 16 QX-mini-LOC knockout and board anchors detail
3. Remove wingnuts to the door ground straps and then remove the doors from the
chassis. Secure wingnuts for future use.
44
Standoffs
Installation
Ground Wire
Anchor
Knockouts
