Mount screws at
these points and
then tighten.
Mount screws at
these points and
then tighten.
Figure 14 QX-mini-LOC mounting holes
5. Fasten two screws halfway into the wall in the positions marked in step 4, using a
suitable screw size.
6. Hang the box onto the two screws.
7. Screw the other two screws at the bottom of the panel.
8. Tighten all four screws into place.
42
Knockouts
8.5"
20.25"
