5.5
Remote Microphone Indicators
The QX-mini-RM remote microphone display panel has 4 LED indicators and 1 control (the
push-to-talk button on the microphone). This section describes the purposes of these
indicators.
i
Note:
Figure 59 The QX-mini-RM display panel LEDs
92
Descriptions of QAD-30 amplifier module LEDs
Color
Green
Green
Yellow
Yellow
Yellow
RM not for use in Canada.
!
Indication
Status
Status
Status
Status
Trouble
AC Power
Common Trouble
Ready to Page
System in Use
Indicators & Controls
Action
Steady
Steady
Steady
Steady
Steady
