Appendix A: Specifications And Features; Table 19 Qx-Mini And Qx-Mini-Bp Specifications And Features - Mircom QX-mini Installation And Operation Manual

11.0
Table 19
QX-mini and QX-mini-BP Chassis
General
NAC Circuits
Aux. Power Supply
Auxiliary relays
(resistive loads)
Electrical ratings
Battery
Compliance
124
Appendix A: Specifications And
QX-mini and QX-mini-BP Specifications and Features
Micro-controller based design and software configurator.
2 Style Y or Z (Class B or A) configurable as strobes or audibles. Terminals are
labelled "NAC 1" and "NAC 2".
Power limited / Regulated 24 VDC / 2.5 Amp @ 49° C per Circuit
Terminal labelled AUX 24V.
Power limited / 24 VDC Filtered (special application) / 0.2 Amp @ 49° C
Special applications compatible for the following devices:
• QX-mini-RM
• QX-mini-LOC
Must be connected to a Listed Power-Limited Source of Supply. Terminals are
labelled COM TBL, AC TBL, and ALARM.
Common Trouble
AC Trouble
Alarm
AC line voltage
Power supply rating
NAC Circuits
Type
Charging capability
Maximum charging current
System Model
Applicable Standards
Environmental
30 VDC, 1 Amp
30 VDC, 1 Amp
30 VDC, 1 Amp
120VAC 60Hz/240VAC 50Hz, 20A slow blow
fuse on secondary of transformer
29VAC 10A maximum (secondary of
transformer)
120VAC 60Hz 3.1Amp (maximum primary of
transformer)
240VAC 50Hz 1.57Amp (maximum primary of
transformer)
Total load not to exceed 9.5A at 24VDC
24VDC regulated, Power-Limited
5 Amp Total, 2.5 Amp maximum per circuit
2 x 12VDC, Gel-Cell/Sealed Lead-Acid
12Ah to 75Ah batteries
5 Amp
QX-mini Small Audio System
UL-1711 Rev 4, UL-864 Rev 9, and ULC-S527 -
2011
Use in indoor and dry environment only.
Features
