USB Interface

3G USB MODEMS
SPEED
CONNECTOR

Configuration Interface

LOCAL TERMINAL
CONNECTOR

Power Supply

INPUT VOLTAGE
INPUT CURRENT
JACK
INTERNAL PIN

External Power Supply

INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY

Dimensions and weight

TYPE
LENGTH x WIDTH x
HEIGHT
WEIGHT

Environmental Specifications

TEMPERATURE
RELATIVE HUMIDITY
Please see the Teldat website
get a list of the supported 3G USB modems.
The interface complies with the USB 2.0 (480
Mbps) standard; the end speed depends on the
3G USB modem used.
USB Type A
V.24 9.600-8-N-1-without flow control.
RJ45 female on the device front panel.
+12V DC.
1200 mA
5,5 mm
2,5 mm
100-240V AC
1.0 A
50-60 Hz
Desktop.
242 x 179 x 48 mm.
0.8 Kg.
OPERATING NORMALLY: 0ºC to 45ºC
STORED: -30ºC to 85ºC
On: 5% to 90%
TELDAT V
– Installation Manual
I - 30
