Chapter 2: Jumpers and Connectors

M.2 Key B Connector

Connector location: M.2_Key_B1
75
74
1
2
Pin
Definition
1
GND
3
GND
5
GND
7
USB2_P6
9
USB2_N6
11
GND
13
15
17
19
21
NC
23
NC
25
NC
27
GND
29
USB3_RX2N
31
USB3_RX2P
33
GND
35
USB3_TX2N_1
37
USB3_TX2P_1
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
3VSB
4
3VSB
6
NC
8
W_DISABLE1#
10
NC
12
14
16
18
20
NC
22
NC
24
NC
26
NC
28
UIM_VPP1
30
UIM_RESET1
32
UIM_CLK1
34
UIM_DATA1
36
UIM_PWR1
38
NC
Pin
Definition
39
GND
41
SATA_RXP1_S
43
SATA_RXN1_S
45
GND
47
SATA_TXN1_S
49
SATA_TXP1_S
51
GND
53
NC
55
NC
57
GND
59
NC
61
NC
63
NC
65
NC
67
M.2_RESET
69
CONFIG_1
71
GND
73
GND
75
CONFIG_2
28
Pin
Definition
40
NC
42
NC
44
NC
46
NC
48
NC
50
PLTRST_N
52
PCIE_CLKREQ3#
54
3P3_WAKE0#
56
NC
58
NC
60
NC
62
NC
64
NC
66
NC
68
PMU_SUSCLK
70
3VSB
72
3VSB
74
3VSB
NISE 51 User Manual
