LAN1 LED Signal Pin Header

Connector type: 2x2 4-pin header, 2.0mm pitch
Connector location: JP8
4 3
2 1
Pin Definition
1 LAN1_ACT_P
3 LAN1_LINK1G#
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 LAN1_LED_ACT#
4 LAN1_LINK100#

LAN2 LED Signal Pin Header

Connector type: 2x2 4-pin header, 2.0mm pitch
Connector location: JP9
4 3
2 1
Pin Definition
1 LAN2_ACT_P
3 LAN2_LINK1G#
23
Pin Definition
2 LAN2_LED_ACT#
4 LAN2_LINK100#
