Chapter 4: BIOS Setup
Serial Port 4 Configuration
This section is used to configure serial port 4.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
Serial Port 4 Configuration
Serial Port [Enabled]
Device Settings IO=2E8h; IRQ=10;
Version 2.18.1263. Copyright (C) 2019 American Megatrends, Inc.
Serial Port
Enables or disables the serial port.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Hardware Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Enable or Disable Serial Port
(COM)
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
CPU temperature(DTS)
Detects and displays the current CPU temperature.
System temperature
Detects and displays the current system temperature.
VCore to VCC3
Detects and displays the output voltages.
