Power Consumption Management
Purpose
The purpose of the power consumption test is to verify the power dissipation
of system, and the loading of power supply.
Test Equipment / Software
1. DC power supply
2. Operating System OS: Windows 10 Pro 64-bit
3. Burn-In Test Ver: 8.1 Pro (1025)
4. Intel Thermal Analysis Tool software version: 6.0.1013
®
5. Network test program
6. Function port fixture:
Functional Port Front / Rear Panel
USB 2.0 x2 5V, 0.5A (Cement Resistor)
USB 3.0 x2 5V, 1.0A (Cement Resistor)
COM 1, COM 2 RS232 Loopback (115200 baud rate)
Display Interface Display Interface LCD Monitor + 5M Display Port Cable
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
C
oWer onsumPtIon
Device Under Test
DUT: NISE 51/ Revision: B
CPU: Intel ® Celeron ® CPU N3350 @ 1.10 GHz
BIOS: American Megatrends / N051-003 X64
Test Procedure
1. Make sure mechanical structure and electrical functionality are normal
before testing.
2. Install all I/O load devices and according as system input voltage
specifications to set up DC Power supply voltage.
3. Measure system maximum power consumption as below mode:
– BIOS mode.
– ACPI Sleep State Mode (S3).
– 100% Full loading mode (Include USB load fixture)
4. Measure and record system maximum power consumption value.
