Chapter 4: BIOS Setup
Trusted Computing
This section is used to configure Trusted Platform Module (TPM) settings.
Aptio Setup Utility - Copyright (C) 2019 American Megatrends, Inc.
Advanced
TPM20 Device Found
Vendor: IFX
Firmware Version: 5.62
Security Device Support [Enable]
Active PCR banks SHA-1,SHA256
Available PCR banks SHA-1,SHA256
SHA-1 PCR Bank [Enabled]
SHA256 PCR Bank [Enabled]
Pending operation [None]
Platform Hierarchy [Enabled]
Storage Hierarchy [Enabled]
Endorsement Hierarchy [Enabled]
[TCG_2]
TPM2.0 UEFI Spec Version
Physical Presence Spec Version [1.3]
TPM 20 InterfaceType [TIS]
Device Select [Auto]
Version 2.19.1266. Copyright (C) 2019 American Megatrends, Inc.
Security Device Support
Enables or disables BIOS support for security device. O.S will not show
Security Device. TCG EFI protocol and INT1A interface will not be available.
SHA-1 PCR Bank
Enables or disables SHA-1 PCR Bank.
SHA256 PCR Bank
Enables or disables SHA256 PCR Bank.
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Pending operation
Schedules an operation for the security device.
Platform Hierarchy
Enables or disables platform hierarchy.
Enables or Disables BIOS
Storage Hierarchy
support for security device. O.S.
will not show Security Device.
Enables or disables storage hierarchy.
TCG EFI protocol and INT1A
interface will not be available.
Endorsement Hierarchy
Enables or disables endorsement hierarchy.
TPM2.0 UEFI Spec Version
Configures the TPM 2.0 UEFI spec version.
→←: Select Screen
↑↓: Select Item
Physical Presence Spec Version
Enter: Select
+/-: Change Opt.
Configures the physical presence spec version.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Device Select
ESC: Exit
Configures the TPM version. TPM 1.2 will restrict support to TPM 1.2 devices
and TPM 2.0 will restrict support to TPM 2.0 devices. Auto will support
both TPM 1.2 and 2.0 devices with the default set to TPM 2.0 devices if not
found, and TPM 1.2 devices will be enumerated.
