1 General
Layout and structure of the type plate on gas appliances
Type plate Additional plate
8
Name
Name of appliance
1
Combi Oven
Trade name
2
Element Meaning
C4 Convotherm 4 appli‐
ance series
eT easyTouch controls
eD easyDial controls
numbers Appliance size
xx.yy
GB Gas appliance with
boiler
GS Gas appliance with
water injection
-N for appliances with an
NSK certificate
Electrical values
3
Serial number
4
Element Meaning
Heating Gas appliance (Y, W)
method
Steam gen‐
■
eration
■
method
Appliance
■
size
■
■
■
■
■
■
Year of
■
manufac‐
■
ture
■
Month of
■
manufac‐
■
ture
■
■
Sequential 4 digits
number
Part number
5
Gas data
6
Country ID
7
Gas category
8
Gas factory setting for the appliance
9
Injection (S)
Boiler (B)
6.10 (1)
6.20 (2)
10.10 (3)
10.20 (4)
12.20 (5)
20.10 (6)
20.20 (7)
2014 (14)
2015 (15)
...
January (01)
February (02)
March (03)
...
