3 For your safety
Item Safety device
Venting position of ap‐
5
pliance door
Safety thermostat
6
(no picture)
■
■
Restart after power
7
failure in case clean‐
(no picture)
ing agent was left in
the appliance
Disconnection device
8
(installed by
customer)
Gas shut-off device
9
(installed by
customer)
Only when installing
10
on a wheeled stand:
(no picture)
Retaining device
Boiler
Cooking chamber
Function
Prevents scalding of user's
face and hands from escaping
steam
Switches off the appliance if
temperature too high
Restarts fully automatic oven
cleaning in a defined state af‐
ter power failure
Installed by the customer
■
close to the appliance; easi‐
ly visible and accessible, 3-
pole action, minimum con‐
tact separation 3 mm.
Used to disconnect the ap‐
■
pliance from the power sup‐
ply during cleaning, repair
and servicing work and in a
hazardous situation
Installed by customer close
■
to appliance in easily acces‐
sible position and clearly la‐
beled
Used to disconnect the ap‐
■
pliance from the gas supply
during cleaning, repair and
servicing work and in a haz‐
ardous situation
Restricts the range of move‐
ment of the assembly (plat‐
form plus appliance) at the
customer's site.
38
Check
When appliance is at low tem‐
perature, check door positions
as described in 'Opening and
closing the appliance door
safely' in the user manual
An error code is output in the
event of a fault
(Please contact an authorized
service company to reset the
safety thermostat)
None
Action:
Trip the disconnection de‐
■
vice
Check at the -X10 terminal
■
strip on the appliance that
none of the three phases
carry a live voltage
Action:
Close gas shut-off device
■
Check that the appliance is
■
isolated from the gas supply
Check that the retaining de‐
vice is connected
