9 Technical data
9.1 Dimensions and weights
Dimensions, Convotherm 4 EB/ES
Appliance including packaging
Width
Height
Depth
Appliance excluding packaging
Width for appliance with right-hinged
appliance door
Width for appliances with disappear‐
ing door inclusive of guide fixing
bracket
Height
Depth with appliance door closed
Safety clearances
Rear
Right, for appliance with right-hinged
appliance door
Right, for appliances with disappear‐
ing door
Left
(larger gap recommended for servic‐
ing)
Top (for ventilation)
Dimensions, Convotherm 4 GB/GS
Appliance including packaging
Width
Height
Depth
Appliance excluding packaging
Width for appliance with right-hinged
appliance door
Width for appliances with disappear‐
ing door inclusive of guide fixing
bracket
Height
Depth with appliance door closed
Safety clearances
Rear
Right, for appliance with right-hinged
appliance door
Right, for appliances with disappear‐
ing door
Left
(larger gap recommended for servic‐
ing)
Top (for ventilation)
6.10 6.20
[mm] 1100 1345
[mm] 1010 1010
[mm] 940 1140
[mm] 875 1120
[mm] 966 1211
[mm] 786 786
[mm] 792 992
[mm] 50 50
[mm] 50 50
[mm] 50 50
[mm] 50 50
[mm] 500 500
6.10 6.20
[mm] 1100 1345
[mm] 1010 1010
[mm] 940 1140
[mm] 875 1120
[mm] 966 1211
[mm] 786 786
[mm] 792 992
[mm] 50 50
[mm] 50 50
[mm] 50 50
[mm] 50 50
[mm] 1000 1000
121
10.10 10.20 12.20 20.10 20.20
1100 1345 1410
1280 1280 1615
940 1140 1170
875 1120 1135
966 1211 1247
1058 1058 1406
792 992 1020
50 50 50
50 50 50
50 50 50
50 50 50
500 500 500
10.10 10.20 12.20 20.10 20.20
1100 1345 1410
1280 1280 1615
940 1140 1170
875 1120 1135
966 1211 1247
1058 1058 1406
792 992 1020
50 50 50
50 50 50
50 50 50
50 50 50
1000 1000 1000
1165 1410
2150 2150
970 1170
890 1135
1002 1247
1942 1942
820 1020
50 50
50 50
50 50
50 50
500 500
1165 1410
2150 2150
970 1170
890 1135
1002 1247
1942 1942
820 1020
50 50
50 50
50 50
50 50
1000 1000
