5 Setting up the appliance
Space required for right-hinged door - width and depth
The following diagram and table show the space required for the appliance for different installation and
operating situations. They also show the minimum horizontal distances from adjacent walls and surfa‐
ces. The safety clearances on the left, right and rear must always be complied with.
S1
Meaning
B1 Width requirement, appliance door
open at 90°
B2 Width requirement, appliance door
open at 180°
T Depth requirement when opening
the appliance door
S1 Safety clearance on left-hand side
S2 Safety clearance at rear
S3 Safety clearance on right-hand side [mm] 50
S3
90°
B1
[mm] 995
[mm] 1413
[mm] 1379
[mm] 50
[mm] 50
180°
6.10 6.20 10.10 10.20 12.20 20.10 20.20
1240 995
1863 1413
1784 1379
50 50
50 50
50 50
50
S3
B2
1240 1309 1064
1863 1955 1505
1784 1835 1430
50 50 50
50 50 50
50 50 50
1309
1955
1835
50
50
50
