5 Setting up the appliance
5.9 Setting up a table-top unit on a stand (marine model)
Rules for setting up the appliance safely
Observe the following rules to ensure that the appliance is installed in a stable situation:
The appliance must be screwed or welded to the stand using the appropriate parts.
■
The stand must be screwed or welded to the floor using the appropriate parts.
■
If you intend to load the combi oven using mobile shelf racks or plate racks, the appliance must be
■
installed at the same height as the loading height of the transport trolley. This is automatically the
case if the surface for wheeling up the transport trolley lies at the same level as the surface on
which the combi oven stand is installed.
It must be possible to wheel the transport trolley up to the cooking chamber and to fix it to the roll-in
frame on a horizontal surface that is clear of obstructions.
The following rules must be observed to meet hygiene standards:
For stands that contain shelf levels for food containers, the top cover must be fitted on the stand to
■
prevent dirt getting onto any food held temporarily in the stand.
Setting up the appliance on a stand
1.
2.
Screw the threaded bolts into the threaded holes provided
in the oven stand and tighten the threaded bolts with the
screwdriver.
Weld the top cover along the connecting edges to all four
legs of the stand.
