Dissipated Heat; Water Connection - Convotherm 4 Series Installation Manual

9 Technical data
9.11 Dissipated heat
Convotherm 4 EB/ES
Latent heat
Sensible heat
Convotherm 4 GB/GS
Latent heat
Sensible heat
9.12 Water connection
Convotherm 4 EB ES GB GS
Water supply (cold only)
Water supply
Flow pressure
Pressure gauge in the water supply
6.10, 6.20, 10.10, 10.20
12.20, 20.10, 20.20
Appliance drain
Model 6.10, 6.20, 10.10, 10.20
Model 12.20, 20.10, 20.20
Type
6.10 6.20
[kJ/h] 2100 3500
[kW] 0.58 0.97
[kJ/h] 2500 4500
[kW] 0.69 1.25
6.10 6.20
[kJ/h] 2100 3500
[kW] 0.58 0.97
[kJ/h] 2500 4100
[kW] 0.69 1.14
2 x G 3/4'' fixed connection, optionally including
connecting pipe (min. DN13 / 1/2'')
[kPa] 150 - 600 (1.5 - 6 bar)
[kPa] 100 (1 bar)
[kPa] 150 (1.5 bar)
Fixed connection (recommended) or funnel waste
trap
Fixed connection (recommended) or open tank or
channel/gully
DN DN 50
136
10.10 10.20 12.20
3500 6400 6900
0.97 1.78 1.92
4500 7800 7800
1.25 2.17 2.17
10.10 10.20 12.20
3500 7100 8200
0.97 1.97 2.28
4100 7200 11000
1.14 2.00 3.06
20.10 20.20
6900 11000
1.92 3.06
8900 14100
2.47 3.92
20.10 20.20
7100 12200
1.97 3.39
11000 15400
3.06 4.28
