9 Technical data
Convotherm 4 ES (single-phase FC)
3N~ 400V 50/60Hz (3/N/PE)
Rated power consumption
Convection power
Motor power
Rated current
Fuse rating
Recommended conductor cross-
section for wires laid uncovered in
air up to 5 m in length.
Recommended residual-current de‐
vice
Optional residual-current device
3~ 230 V 50/60Hz (3/PE)
Rated power consumption
Convection power
Motor power
Rated current
Fuse rating
Recommended conductor cross-
section for wires laid uncovered in
air up to 5 m in length.
Recommended residual-current de‐
vice
Optional residual-current device
3~ 200 V 50/60Hz (3/PE)
Rated power consumption
Convection power
Motor power
Rated current
Fuse rating
Recommended conductor cross-
section for wires laid uncovered in
air up to 5 m in length.
Recommended residual-current de‐
vice
Optional residual-current device
6.10 6.20
[kW] 11.0 19.5
[kW] 10.6 19.1
[kW] 0.35 0.35
[A] 15.9 28.1
[A] 16 32
5G4 5G6
2
[mm ]
Type A A
Type B/F B/F
[kW] 10.9 19.3
[kW] 10.5 18.9
[kW] 0.35 0.35
[A] 27.4 48.5
[A] 35 50
4G6 4G16 4G16 4G35 4G35 4G35 4G70
2
[mm ]
Type A A
Type B/F B/F
[kW] 10.9 19.3
[kW] 10.5 18.9
[kW] 0.35 0.35
[A] 31.5 55.8
[A] 35 63
4G6 4G16 4G16 4G35 4G35 4G50 4G95
2
[mm ]
Type A A
Type B/F B/F
126
10.10 10.20 12.20 20.10 20.20
19.5 33.7 33.7
19.1 33.3 33.3
0.35 0.35 0.35
28.1 48.7 48.7
32 50 50
5G6 5G16 5G16 5G16 5G35
A A A
B/F B/F B/F
19.3 33.4 33.4
18.9 33.0 33.0
0.35 0.35 0.35
48.5 84.0 84.0
50 100 100
A A A
B/F B/F B/F
19.3 33.4 33.4
18.9 33.0 33.0
0.35 0.35 0.35
55.8 96.6 96.6
63 100 100
A A A
B/F B/F B/F
38.9 67.3
38.1 66.5
0.7 0.7
56.2 97.3
63 100
A A
B/F B/F
38.2 66.4
37.8 66.0
0.7 0.7
96.0 166.9
100 200
A A
B/F B/F
38.2 66.4
37.8 66.0
0.7 0.7
110.4 191.9
125 200
A A
B/F B/F
