5 Setting up the appliance
5.7 Setting up a table-top unit on a work surface (marine model)
Rules for setting up the appliance safely
Observe the following rules to ensure that the appliance is installed in a stable situation:
The appliance must be screwed or welded to the worktable using the appropriate parts.
■
The worktable must be screwed or welded to the floor.
■
If you intend to load the combi oven using mobile shelf racks or plate racks, the appliance must be
■
installed at the same height as the loading height of the transport trolley. The roll-in frame inserted
in the cooking chamber and the surface on which the mobile shelf rack / plate rack sits on the
transport trolley must be at the same height when the transport trolley is attached to the combi
oven.
It must be possible to wheel the transport trolley up to the cooking chamber and to fix it to the roll-in
frame on a horizontal surface that is clear of obstructions.
Setting up the appliance on a worktable
1.
2.
3.
Position the appliance on the worktable, and on the work‐
top make a precise mark at the corners of each bracket on
each appliance foot.
Remove both brackets from all four appliance feet by un‐
screwing the relevant screw in each case.
Take the appliance off the worktable.
