2 Design and function
Item Name
Side panel
12
Ventilation slots under‐
13
neath the appliance
Type plate
14
Components and function (electric floor-standing units)
The figure below shows a size 20.20 combi oven as an example of all electric floor-standing units:
Item Name
Ventilation port
1
Air vent
2
Door handle
3
Appliance door
4
Operating panel
5
Suction panel
6
Core temperature probe,
7
sous-vide sensor (optional)
Built-in preheat bridge in
8
appliance door
Function
Covers the appliance wiring compartment
Used for appliance ventilation
■
Must not be covered
■
Identifies the appliance
Function
External air intake for removing the moisture removal from the
■
cooking chamber
Smooths out any pressure fluctuations in the cooking chamber
■
Allows hot vapour to escape
Opens and closes the appliance door
■
On-latch position for opening the appliance safely
■
Antibacterial material containing silver ions ("HygienicCare")
■
Closes the cooking chamber
■
Can slide back beside the appliance when opened in order to
■
save space ("disappearing door") (optional)
Used for operating the appliance
■
Antibacterial ("HygienicCare")
■
Distributes the heat evenly inside the cooking chamber
■
Separates the fan compartment from the cooking chamber
■
Measures the core temperature of the food being cooked
■
Available in two connection options: permanent internal con‐
■
nection or temporary external connection
Used for safety purposes during preheating and reduces energy
wastage
