6 Installation
4.
5.
Plug the red extractor tube (4) for the ConvoClean forte or
ConvoClean new cleaning agent onto the connector nip‐
ple of the front tube fitting (G) and secure the tube in
place with the wire clip (3) (see label for cleaning-agent
connection on the left-hand side of the appliance).
Insert the suction nozzle on the red extractor tube into the
cleaning-agent canister (5). There must be no kinks in the
tube and the vent hole in the canister must be open and
unblocked.
