2.3.11 Configure the Sensor Page Parameters
The door sensor (pins 3 and 4) on the terminal block can be used to monitor a door's open or closed
state. There is an option on the
The door sensor alarm will be activated when the
met.
Each sensor can trigger up to three different actions:
•
•
•
Note
1. Click Sensor menu button to open the
Operations Guide
Activate the relay until the sensor is deactivated
Loop an audio file out of the speaker until the sensor is deactivated
Call an extension and play a pre-recorded audio file
Calling a preset extension can be set up as a point-to-point call, but currently can't send
delayed DTMF tones.
Sensor Page to trigger on an open or short condition on these pins.
Sensor Timeout (seconds)
Sensor Page (Figure
931971A
Installing the SIP Paging Amplifier
SIP Paging Amplifier Setup
parameter has been
2-35).
