2.3.9 Configure the Sensor Configuration Parameters

The door sensor (pins 1 and 2) on the terminal block can be used to monitor a door's open or closed
state. There is an option on the
on these pins. The door sensor alarm will be activated when the
parameter has been met.
Each sensor can trigger up to five different actions:
•
•
•
•
•
Note
1. Click Sensor menu button to open the
Operations Guide
Flash the LED until the sensor is deactivated (roughly 10 times/second)
Activate the relay until the sensor is deactivated
Loop an audio file out of the speaker until the sensor is deactivated
Call an extension and establish two way audio
Call an extension and play a pre-recorded audio file
Calling a preset extension can be set up as a point-to-point call, but currently can't send
delayed DTMF tones.
Singlewire InformaCast Loudspeaker Amplifier (AC-Powered) Setup
Sensor Configuration Page
Sensor Configuration Page (Figure
931281B
Configure the Sensor Configuration Parameters
to trigger on an open or short condition
Sensor Timeout (in seconds)
2-31).
