Specifications

6 Specifications

6.1 Servo Drive

6.1.1 Dimensions

Flange
Servo drive Flange thickness
Size 1, 1.5 Nm 7 mm
Size 2, 2.1 Nm –
Size 2, 2.9 Nm 8 mm
Size 2, 3.8 Nm 8 mm
Table 6.1 Flange Thickness
All dimensions are in mm (in).
55.4
[2.18]
Illustration 6.1 Dimensions of ISD 510 Size 1, 1.5 Nm
55.4
[2.18]
Illustration 6.2 Dimensions of ISD 510 Size 2, 2.1 Nm
MG36C102
Design Guide
280
[11.02]
252
[9.92]
Danfoss A/S © 08/2017 All rights reserved.
44.5
[1.75]
30
[1.18]
70
[2.76]
2.5
[0.09]
16
[0.63]
40
[1.57]
80
[3.15]
3
[0.12]
6
83.5
[3.29]
76
[2.99]
83.5
[3.29]
M6 (X4)
[0.236]
84
[3.31]
53
6
