Specifications

11 Specifications

11.1 Nameplate

Check the nameplate and compare it with the order data.
Use the part number for reference.
The part number uniquely identifies the connection box.
ISD Connection Box
1
Connection Box:
2
Uin: 300VDC
3
Iin/max: 10ADC
4
Uout: 300VDC
5
Iout/max: 10ADC
6
Pout/max: 3000W
7
o o o o
Ambient: 5...40 C/41...104 F
8
Enclosure: IP 20
PART NO: 175G7760
175G776000000M000
Made in Germany
Illustration 11.1 Nameplate
The following data is shown on the nameplate of the ISD
connection box:
1 Input voltage 6
2 Max. input current 7
3 Output voltage 8
4 Max. output current 9
5 Max. output power
Table 11.1 Legend to Illustration 11.1
Ensure that the nameplate is clearly legible.

11.2 Storage

Store the connection box in a dry, dust-free location with
low vibration (V ≤0.2 mm/s).
eff
The storage location must be free from corrosive gases.
Avoid sudden temperature changes.
®
VLT ISD Connection Box Operating Instructions
9
SERIAL NO : 000402M352
Ambient temperature
range
Protection rating
Part number
Serial number
®
MG75G102 - VLT is a registered Danfoss trademark

11.3 Characteristic Data

Definition Value and Unit
Input
Input voltage 300 V DC
Connections +300 V DC, –300 V DC, PE
Input current DC 10 A
Fuse protection External via line protection
Power factor 94%
Output (with use of ISD Power Supply Module)
Output voltage line 1 300 V DC
Output voltage line 2 300 V DC
Tolerance ±1%
Ripple 1 V
pp
Rated power 3.0 kW
Rated current
10 A
Environmental Conditions
Climatic classification 3K3
Mounting In a control cabinet
Ambient temperature 5–40 °C
Humidity 5-85%, non-condensing
(according to IEC 60721-3-3)
Cooling Via vents on housing
Protection type IP20
Protection rating 1 with PE connection
Over-voltage category III
Vibration rating 3M4
Mechanical Conditions
Degree of pollution 2
Safety Standards EN 61508
Housing
Material Steel, aluminium for wall mounting
Dimensions (W x H x D) 130 x 268 x 200 mm
Weight 5 kg
Table 11.2 Characteristic Data
1) Only if 10 A is fed in
1)
