WARNING
DISCHARGE TIME
The servo drives and the SAB contain DC-link capacitors
that remain charged for some time after the mains
supply is switched off at the SAB. Failure to wait the
specified time after power has been removed before
performing service or repair work could result in death
or serious injury.
•
To avoid electrical shock, fully disconnect the
SAB from the mains and wait for at least the
time listed in Table 1.3 for the capacitors to fully
discharge before carrying out any maintenance
or repair work on the ISD 510 servo system or
its components.
Number
0–64 servo drives
Table 1.3 Discharge Time
NOTICE
Never connect or disconnect the hybrid cable to or from
the servo drive when the ISD 510 servo system is
connected to mains or auxiliary supply, or when voltage
is still present. Doing so damages the electronic circuitry.
Ensure that the mains supply is disconnected and the
required discharge time for the DC-link capacitors has
elapsed before disconnecting or connecting the hybrid
cables or disconnecting cables from the SAB.
NOTICE
Full safety warnings and instructions are detailed in the
®
VLT Integrated Servo Drive ISD 510 System Operating
Instructions.

1.7 Terminology

®
VLT Integrated
Servo Drive ISD
510
®
VLT Servo Access
®
Box SAB
PLC
Loop cable
Feed-in cable
Table 1.4 Terminology
An explanation of all terminology and abbreviations can be
found in chapter 7.1 Glossary.
10
VLT
Minimum waiting time (minutes)
10
Integrated servo drive
Unit that generates the DC-link voltage and
passes the U , Real-Time Ethernet, UDC,
AUX
and STO signals to the servo drives via a
hybrid cable.
External device for controlling the VLT
®
Integrated Servo Drive ISD 510 System.
Hybrid cable for connecting servo drives in
daisy-chain format.
Hybrid cable for connection from the SAB to
the 1 st servo drive.
