Danfoss VLT ISD 510 Design Manual page 71

Specifications
Number Description/connector name
1 Local control panel (LCP)
2 Front cover
3 STO 1 IN: STO
(Used for STO input voltage 1)
4 STO 1 IN: 24 V
(Used for bridging when the STO function
is not required, see chapter 6.2.3.1 STO
Connectors)
5 LEDs for status of auxiliary output and
STO
6 Decoupling clamp for STO cable
7 ISD Line 2: STO 2
(STO output to hybrid cable line 2)
8 ISD Line 2: NET 2 X4
(Ethernet output to hybrid cable line 2)
9 ISD Line 2: AUX 2
(Auxiliary output to hybrid cable line 2)
10 ISD Line 2: UDC 2
(UDC output to hybrid cable line 2)
11 ISD Line 1: STO 1
(STO output to hybrid cable line 1)
12 ISD Line 1: NET 1 X3
(Ethernet output to hybrid cable line 1)
13 ISD Line 1: AUX 1
(Auxiliary output to hybrid cable line 1)
14 ISD Line 1: UDC 1
(UDC output to hybrid cable line 1)
15 Grounding PE clamp for hybrid cable line
2
16 Grounding PE clamp for hybrid cable line
1
17 Hybrid cable line 1
Table 6.13 Legend to Illustration 6.30
MG36C102
Design Guide
Name on Number
corresponding
connector
– 18
– 19
+STO– 20
+24V– 21
– 22
– 23
+STO– 24
RJ45 connector 25
(without label)
+AUX– 26
+UDC– 27
+STO– 28
RJ45 connector 29
(without label)
+AUX– 30
+UDC– 31
– 32
– 33
– –
Danfoss A/S © 08/2017 All rights reserved.
Description/connector name Name on
corresponding
connector
Hybrid cable line 2 –
Decoupling plate –
Shielded cable grounding –
clamp and strain relief
24/48 V IN +AUX–
(Auxiliary input terminal)
Relay 1 Relay 1
Relay 2 Relay 2
Brake R– (81), R+ (82)
Mains L1 (91), L2 (92), L3
(Input terminal) (93)
Fixture for Ethernet inputs –
Decoupling clamp for encoder –
cable
X1 RJ45 connector
(Ethernet input line 1) (not included)
X2 RJ45 connector
(Ethernet input line 2) (not included)
GND, 24 V, GX, /RS422 TXD, Not labeled
RS422 TXD, /RS422 RXD, RS422
RXD
(Encoder terminal)
STO 2 IN: STO +STO–
(Used for STO input voltage 2)
STO 2 IN: 24 V +24V–
(Used for bridging when the
STO function is not required,
see chapter 6.2.3.1 STO
Connectors)
Cover –
– –
