System Overview
Interface
Shaft
2 2
Operating LEDs
M23 hybrid input connector
M23 hybrid output
connector
M8 4-pole connector
(advanced servo drive only)
M12 8-pole connector
(advanced servo drive only)
M8 6-pole connector
(advanced servo drive only)
Table 2.1 External Interfaces on the ISD 510 Servo Drive
The ISD 510 servo drive has the flange sizes shown in
Table 2.2.
Flange size
Table 2.2 Motor and Flange Sizes
All dimensions of the servo drive are listed in
chapter 6.1.1 Dimensions.

2.3 System Wiring

2.3.1 Ethernet POWERLINK
Redundancy

2.3.1.1 Standard Cabling Concept for 1 Line

Real-Time Ethernet
SAB
AUX 1
AUX 2
SAFE 1
SAFE 2
Quick Main Alarm
Status
Menu Menu Log
OK
Hand Auto
Reset
On On
ISD 510
1 M23 Feed-in cable
2 M23 Loop cable
Illustration 2.2 Standard Cabling Concept for 1 Line
12
VLT
Description
Mechanical interface.
Provides the status of the servo
drive.
Input connector for power and
communication signals.
Output connector for power and
communication signals.
Input connector for fieldbus
devices.
Input connector for external
encoder or I/Os.
Input connector for LCP.
Size 1, Size 2, Size 2,
1.5 Nm 2.1 Nm 2.9 Nm
76 mm 84 mm
®
without
400-480 V AC
1 2
. . .
Danfoss A/S © 08/2017 All rights reserved.
® ®
Integrated Servo Drive ISD
2.3.1.2 Standard Cabling Concept for 2
Lines
Real-Time Ethernet
SAB
AUX 1
AUX 2
SAFE 1
SAFE 2
Status Quick Main Alarm
Menu Menu Log
OK
Hand Auto
Reset
On On
ISD 510
Size 2,
3.8 Nm
1 M23 Feed-in cable
2 M23 Loop cable
Illustration 2.3 Standard Cabling Concept for 2 Lines
Quick Main Alarm
Status Menu Menu Log
OK
Hand On On Auto Reset
LCP
510 System
400-480 V AC
1 2
. . .
. . .
Quick Main Alarm
Status Menu Menu Log
OK
Hand Auto
On On Reset
LCP
MG36C102
