Typecode and Selection

5 Typecode and Selection
5.1 Drive Configurator for VLT
The Danfoss Drive Configurator (vltconfig.danfoss.com) is an advanced but easy-to-use tool to configure the Danfoss VLT
Integrated Servo Drive ISD 510 that exactly matches your requirements.
NOTICE
The Drive Configurator shows the valid configuration of servo drive variants. Only valid combinations are shown.
5 5
Therefore, not all variants detailed in the type code (see chapter 5.2.1 Typecode and Definitions) are visible.
The Drive Configurator generates a unique code number for the servo drive required, preventing errors during order entry.
Decoding is also available: Enter a typecode and the Drive Configurator decodes the configuration and show the configu-
ration of the servo drive.
5.2 VLT ®
Integrated Servo Drive ISD 510

5.2.1 Typecode and Definitions

Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
Fixed I S D 5 1 0
Variant
Table 5.1 Type Code
[01–03] Product group
ISD ®
VLT
[04–06] Product variant
510
®
ISD
[07] Hardware configuration
A Advanced
S
Standard
[08] Drive torque
T Torque
[09–12] Torque
01C5 1.5 Nm
02C1
2.1 Nm
02C9 2.9 Nm
03C8 3.8 Nm
[13–14] DC voltage
D6 600 V DC-link voltage
[15–17] Drive enclosure
E54 IP54
E67
IP67 (shaft IP65)
[18–20] Drive feedback
FRX Resolver
FS1 Single-turn feedback
FM1 Multi-turn feedback
Table 5.2 Legend to Typecode
1) In preparation
50
®
Integrated Servo Drive ISD 510
T D 6
A 0 1 C 5
S 0 2 C 1
0 2 C 9
0 3 C 8
[21–22]
PL
Integrated Servo Drive
EC
PN
510
EN
[23–25]
SXX
SC0
[26]
T
F
[27–30]
F076
F084
F108
F138
[31–32]
SX
C0
Danfoss A/S © 08/2017 All rights reserved.
®
VLT Integrated Servo Drive ISD
E 5 4 F R X P L S X X T F 0 7 6 S X N 4 6 X S X S X
E 6 7 F S 1 E C S C O F F 0 8 4 C 0 N 4 0 B K S C X
F M 1 P N
E N
Bus system
®
Ethernet POWERLINK
®
EtherCAT
®1)
PROFINET
1)
EtherNet/IP™
Firmware
Standard
Customized version
Safety
Safe Torque Off (STO)
Functional safety 1)
Flange size
76 mm
84 mm
1)
108 mm
1)
138 mm
Flange type
Standard
Customized version
®
510 System
F 1 0 8 N 2 9
F 1 3 8 N 2 4
[33–35] Motor speed
N46 Rated speed 4600 RPM
N40 Rated speed 4000 RPM
N29
Rated speed 2900 RPM
N24 Rated speed 2400 RPM
[36] Mechanical brake
X
Without brake
B With brake
[37] Motor shaft
S Standard smooth shaft
K
Standard fitted key
C
Customized
[38] Motor sealing
X Without sealing
S With sealing
[39–40] Surface coating
SX Standard
CX Customized
®
C
1)
