Servo Access Box; Options; Mechanical Holding Brake; Feedback - Danfoss VLT ISD 510 Design Manual

Typecode and Selection

5.3 Servo Access Box

Description
® ®
VLT Servo Access Box (SAB ) with Ethernet
®
POWERLINK
® ®
VLT Servo Access Box (SAB ) with EtherCAT
Table 5.3 SAB Ordering Numbers

5.4 Options

5.4.1 Mechanical Holding Brake

The optional mechanical holding brake is designed as a
single-disc brake. The emergency stop function can be
initiated at most once every 3 minutes and up to 2000
times in total, depending on the load.
The effective holding torque is:
•
Size 1: 2.5 Nm
•
Size 2: 5.3 Nm
The brake operates as a holding brake according to the
fail-safe principle closed when no current. It is powered
from the 24–48 V DC auxiliary supply. This enables low-
backlash load holding when no current is present.
Power consumption:
•
Size 1: 2.0 W
•
Size 2: 2.5 W
NOTICE
Do not misuse the holding brake as a working brake
because this causes increased wear, resulting in
premature failure.

5.4.2 Feedback

5.4.2.1 Built-in Feedback Devices

The built-in feedback device measures the rotor position.
There are 3 feedback variants available:
•
Resolver
•
17-bit single-turn encoder
•
17-bit multi-turn encoder
Table 5.4 summarizes the characteristic data of each
variant.
Data/type Resolver Single-turn
encoder
Signal Sin/cos BiSS-B
±10 arcmin ±1.6 arcmin
Accuracy
Resolution 14 bit 17 bit
Maximum – –
number of turns
Table 5.4 Characteristic Data of Available Feedback Devices
MG36C102
Design Guide

5.4.3 Customized Flange

Ordering
A customized flange is available on request. Contact
number
Danfoss for further information.
175G0117

5.4.4 Shaft Seal

® 175G0118
The servo drives can be sealed by a shaft seal (optional) to
achieve up to IP65 on the A-side of the motor.
Description
Shaft seal set for size 1 servo drive (10 pieces) 175G8192
Shaft seal set for size 2 servo drive (10 pieces) 175G8191
Table 5.5 Shaft Seal Ordering Numbers
See chapter 4.5.1.3 24 V Supply for further information on IP
ratings.

5.5 Accessories

5.5.1 Flexible Hybrid Cable

5.5.1.1 Feed-In Cable

Description
Hybrid feed-in cable M23, 90° angled
connector
Hybrid feed-in cable M23, straight
connector
Multi-turn
encoder
Table 5.6 Feed-In Cable Ordering Numbers
BiSS-B
±1.6 arcmin
17 bit
4096 (12 bit)
Danfoss A/S © 08/2017 All rights reserved.
Ordering
5
number
Length Ordering
[m] number
2 175G8920
4 175G8921
6 175G8922
8 175G8923
10 175G8924
15 175G8925
20 175G8926
25 175G8927
30 175G8928
40 175G8929
2 175G8930
4 175G8931
6 175G8932
8 175G8933
10 175G8934
15 175G8935
20 175G8936
25 175G8937
30 175G8938
40 175G8939
51
5
