12 Specifications

12.1 Nameplate

Check the nameplate and compare it with the order data.
Use the part number for reference.
The part number uniquely identifies the drive type.
ISD410
1
SERVO - DRIVE:
2
Uin : 300VDC
3
linS3 : 4ADC 6% ED 120s linS1: 0,2ADC
4
MnS3: 8Nm 6% ED 120s MnS1: 2,1Nm
5
AMBIENT : 5...40 C/41...104 F
6
ENCLOSURE: IP65
7
Nn: 600rpm
PART NO: 175G7825
Illustration 12.1 Nameplate
The following data is shown on the nameplate of the ISD
motor:
1 Supply voltage
2 Current details
3 Power rating
12 12
4 Ambient temperature range
5 Protection rating
Table 12.1 Legend to Illustration 12.1
Check that the nameplate is clearly legible.
The servomotors can be identified externally only by the
original Danfoss nameplate.

12.2 Storage

Store the servomotors in a dry, dust-free location with low
vibration (v
eff
The storage location must be free from corrosive gases.
Avoid sudden temperature changes.
38
o o
8
Brake: no brake
SERIAL NO : 000101M112
*175G782500010M112*
Made in Germany
6
7
8
9
10
≤0.2 mm/s).
MG75D102 - VLT
®
VLT ISD 410 Servomotor Operating Instructions

12.2.1 Long-term Storage

NOTE
To recondition the electrolytic capacitors, servomotors not
in service must be connected to a supply voltage source
once per year to allow the capacitors to charge and
discharge, as otherwise the capacitors will suffer
permanent damage.
