Introduction
The ISD 410 servo system is designed to accommodate up
to 60 ISD 410 servomotors and consists of:
2
2
•
1 Power supply module
•
1 Connection box
•
1 Encoder Box
•
Servomotors
•
1 Master
•
Hybrid cables
NOTE
The ISD 410 servomotors cannot be used in other servo
systems from other manufacturers!
Motors from other manufacturers cannot be used in the
Danfoss ISD 410 servo system!
2.2 Terminology
ISD
ISD servo system
ISD master
ISD master system Control system hardware and software
ISD servo drive
Table 2.2 Terminology
2.3 Purpose of the Operating Instructions
The purpose of these operating instructions is to describe
the Danfoss ISD connection box exclusively in the context
of a Danfoss ISD 410 servo system.
These operating instructions contain information about:
•
Installation
•
Commissioning
•
Operation
•
Troubleshooting
•
Maintenance and repair
These operating instructions are intended for use by
qualified personnel. Read these operating instructions in
full in order to use the servo system safely and profes-
sionally, and pay particular attention to the safety
instructions and general warnings. These operating
instructions are an integral part of the ISD connection box.
Keep these operating instructions available with the servo
system at all times.
8
®
VLT
Integrated Servo Drives
Complete system including all components.
Control system hardware
ISD servomotor with hybrid cable
MG75G102 - VLT
ISD Connection Box Operating Instructions
Compliance with the information in the operating
instructions is a prerequisite for:
•
Trouble-free operation
•
Recognition of product liability claims
Therefore, read these operating instructions before
working with the connection box!
The operating instructions also contain important service
information. The operating instructions should therefore be
kept close to the connection box.
2.4 Additional Resources
Available documents for the ISD 410 servo system:
Document
®
VLT
ISD 410
Servomotor Operating
Instructions
®
VLT
ISD Encoder Box
Operating Instructions
®
VLT
ISD Connection Box
Operating Instructions
®
VLT
ISD Power Supply
Module Operating
Instructions
®
VLT
ISD 410 Design
Guide
Table 2.3 Available Documents for the ISD 410 Servo System
Technical literature for Danfoss drives is also available
online at http://www.danfoss.com/BusinessAreas/DrivesSo-
lutions/Documentations/Technical+Documentation.htm.
Firmware updates may be available. When firmware
updates are available, they can be downloaded from the
www.danfoss.com website. For further information see the
®
VLT
ISD 410 Design Guide.
®
is a registered Danfoss trademark
Contents
Information about the commissioning
and operation of the servomotors
Information about the commissioning
and operation of the encoder box
Information about the commissioning
and operation of the connection box
Information about the commissioning
and operation of the power supply
module
Information about the construction
and commissioning of the ISD 410
servo system
